A comparative retrospective analysis of the results of hybrid interventions and femoral-tibial bypass in extended multi-level infrainguinal arterial segment lesions in patients with chronic critical limb ischemia

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

Background:  The traditional approach to the revascularization of the lower limb in critical ischemia (CLTI) caused by extended occlusion of the superficial femoral artery (SFA) in the passable popliteal artery (PA) and severe occlusive lesions of the tibial arteries suggests femoral-tibial bypass (FTB).

Materials and Methods: The clinical research included patients suffering from chronic limb threatening ischemia (CLTI) (chronic arterial insufficiency 4 stage), with extended (>20 cm) occlusion of the femoral-popliteal segment arteries and severe damage to the outflow pathways. The patients were divided in to two groups according to the criteria of the clinical picture and methods of surgical intervention.

Results: The 30-day mortality and graft failure rate were 2.5% vs 4.3% (p>0.05) and 5% vs 13% (p<0.05) after hybrid and tibial bypass interventions, respectively.

At 1 year the primary patency of bypass and amputation-free survival were 77.7% (95% CI 61.7-93.7) vs 57.1% (95% CI 42.9-71.3) and 82.1% (95% CI 66.8-97.4) vs 69.6% (95% CI 56.1-83.1) after hybrid intervention and tibial bypass, respectively (all non-significant).

Conclusions: Compared to femoral tibial bypass, a hybrid intervention comprised of a bypass to a patent popliteal artery and subsequent crural angioplasty decreased the early failure rate without any negative effect on the long-term outcomes in CLI patients with long SFA CTO and extensive runoff disease.

About the authors

Arshed Ahmad Kuchay

Saint Petersburg State Pediatric Medical University; City Hospital No. 14

Author for correspondence.
Email: drarshedcvs@gmail.com
ORCID iD: 0000-0002-7974-9369
SPIN-code: 5455-9033

MD, MS, Senior Lecturer at Department of Human Anatomy; Cardiovascular Surgeon, Clinical Researcher at City Limb Salvage Center

Russian Federation, Saint Petersburg; Saint Petersburg

Aleksandr N. Lipin

City Hospital No. 14; Kirov Military Medical Academy

Email: a_lipin2001@mail.ru
ORCID iD: 0000-0002-8347-8821
SPIN-code: 6751-9628

MD, PhD, Dr. Sci. (Medicine), Professor; Chairman of the City Limb Salvage Center

Russian Federation, Saint Petersburg; Saint Petersburg

References

  1. Aboyans V, Ricco JB, Bartelink MEL, et al. 2017 ESC Guidelines on the Diagnosis and Treatment of Peripheral Arterial Diseases, in collaboration with the European Society for Vascular Surgery (ESVS): Document covering atherosclerotic disease of extracranial carotid and vertebral, mesenteric, renal, upper and lower extremity arteries endorsed by: the European Stroke Organization (ESO) The Task Force for the Diagnosis and Treatment of Peripheral Arterial Diseases of the European Society of Cardiology (ESC) and of the European Society for Vascular Surgery (ESVS). Eur Heart J. 2018;39(9): 763–816.
  2. Ah Chong AK, Tan CB, Wong MW, et al. Bypass surgery or percutaneous transluminal angioplasty to treat critical lower limb ischaemia due to infrainguinal arterial occlusive disease? Hong Kong Med J. 2009;15(4):249–254.
  3. Alexandrescu VA, Brochier S, Limgba A, et al. Healing of diabetic neuroischemic foot wounds with vs without wound-targeted revascularization: preliminary observations from an 8-year prospective dual-center registry. J Endovasc Ther. 2020;27(1):20–30.
  4. Attinger CE, Evans KK, Bulan E, et al. Angiosomes of the foot and ankle and clinical implications for limb salvage: reconstruction, incisions, and revascularization. Plast Reconstr Surg. 2006;117(7):261S-293S. doi: 10.1097/01.prs.0000222582.84385.54
  5. Berli M, Wanivenhaus F, Kabelitz M et al. Predictors of reoperation after lower limb amputation in patients with peripheral arterial disease. Vasa. 2019;48:419–424. doi: 10.1024/0301-1526/a000796
  6. Biancari F, Albäck A, Ihlberg L, et al. Angiographic runoff score as a predictor of outcome following femorocrural bypass surgery. Eur J Vasc Endovasc Surg. 1999;17(6):480–485. doi: 10.1053/ejvs.1999.0825
  7. Bisdas T, Torsello G, Stachmann A, et al. CRITISCH study group. Results of peripheral bypass surgery in patients with critical limb ischemia (CRITISCH registry). Gefasschirurgie. 2016;21(2):71–79. doi: 10.1007/s00772-016-0166-2
  8. Blair JM, Gewertz BL, Moosa H, et al. Percutaneous transluminal angioplasty versus surgery for limb-threatening ischemia. J Vasc Surg. 1989;9(5):698–703. doi: 10.1067/mva.1989.vs0090698
  9. Bradbury AW, Adam DJ, Bell J, et al. Bypass versus Angioplasty in Severe Ischaemia of the Leg (BASIL) trial: A description of the severity and extent of disease using the Bollinger angiogram scoring method and the TransAtlantic Inter-Society Consensus II classification. J Vasc Surg. 2010;51(5):32S-42S. doi: 10.1016/j.jvs.2010.01.075
  10. Brochado NF, Gonzalez J, Cinelli M Jr, et al. Bypass to the genicular arteries for revascularisation of the lower limb. Eur J Vasc Endovasc Surg. 2000;20(6):545–549. doi: 10.1053/ejvs.2000.1236
  11. Brewster DC, Charlesworth PM, Monahan JE, et al. Isolated popliteal segment v tibial bypass. Comparison of hemodynamic and clinical results. Arch Surg. 1984;119(7):775–779. doi: 10.1001/archsurg.1984.01390190019004
  12. Chung J, Modrall JG, Knowles M, et al. Arteriographic patterns of atherosclerosis and the association between diabetes mellitus and ethnicity in chronic critical limb ischemia. Ann Vasc Surg. 2017;40:198–205. doi: 10.1016/j.avsg.2016.11.003
  13. Cotroneo AR, Iezzi R, Marano G, et al. Hybrid therapy in patients with complex peripheral multifocal steno-obstructive vascular disease: two-year results. Cardiovasc Intervent Radiol. 2007; 30:355–361. doi: 10.1007/s00270-005-0296-5
  14. Clark TW, Groffsky JL, Soulen MC. Predictors of long-term patency after femoropopliteal angioplasty: results from the STAR registry. J Vasc Interv Radiol. 2001;12(8):923–933. doi: 10.1016/s1051-0443(07)61570-x
  15. Conte MS, Bradbury AW, Kolh P, et al. Global vascular guidelines on the management of chronic limb-threatening ischemia. Eur J Vasc Endovasc Surg. 2019;58(1S):S1–S109.e33. doi: 10.1016/j.ejvs.2019.05.006
  16. Davies MG, Saad WE, Peden EK, et al. Impact of runoff on superficial femoral artery endoluminal interventions for rest pain and tissue loss. J Vasc Surg. 2008;48(3):619–625.
  17. Donaldson MC, Mannic JA, Whittermore AD. Femoral-distal bypass with in situ greater saphenous vein. Long term results using the Mills valvulotome. Ann Surg. 1991;213(5):457–464. doi: 10.1097/00000658-199105000-00011
  18. Gerhard-Herman MD, Gornik HL, Barrett C, et al. 2016 AHA/ACC Guideline on the management of patients with lower extremity peripheral artery disease: executive summary: a report of the American College of Cardiology/American Heart Association task force on clinical practice guidelines. J Am Coll Cardiol. 2017;69(11):1465–1508. doi: 10.1016/j.jacc.2016.11.008
  19. Gruss JD, Heimer W. Results of femoropopliteal and femorotibial greater saphenous vein in situ bypass. Life table analysis. Int Angiol. 1992;11(2):94–105.
  20. Heimer W, Uy J, Geissler C, et al. Femoropopliteal and femorotibial greater saphenous vein «in situ» reconstructions in non selected patients. Life table analysis. J Cardiovasc Surg (Torino). 1993;34(4):303–305.
  21. Hiramori S, Soga Y, Tomoi Y, et al. Impact of runoff grade after endovascular therapy for femoropopliteal lesions. J Vasc Surg. 2014;59(3):720–727. doi: 10.1016/j.jvs.2013.09.053
  22. Ishii Y, Gossage JA, Dourado R, et al. Minimum internal diameter of the greater saphenous vein is an important determinant of successful femorodistal bypass grafting that is independent of the quality of the runoff. Vascular. 2004;12(4):225–232. doi: 10.1258/rsmvasc.12.4.225
  23. Ihnat DM, Duong ST, Taylor ZC, et al. Contemporary outcomes after superficial femoral artery angioplasty and stenting: the influence of TASC classification and runoff score. J Vasc Surg. 2008;47(5): 967–974. doi: 10.1016/j.jvs.2007.12.050
  24. Iida O, Takahara M, Soga Y, et al. Impact of angiosome-oriented revascularization on clinical outcomes in critical limb ischemia patients without concurrent wound infection and diabetes. J Endovasc Ther. 2014;21(5):607–615. doi: 10.1583/14-4692R.1
  25. Kobayashi N, Hirano K, Yamawaki M et al. Clinical effects of single or double tibial artery revascularization in critical limb ischemia patients with tissue loss. J Vasc Surg. 2017;65:744–753. doi: 10.1016/j.jvs.2016.08.106
  26. Kuchai AA, Lipin AN, Antropov AV, et al. Treatment of multilevel lesions of arteries in lower extremities in cases of CLTI. Medical Alliance. 2022;10(S3):187–189. EDN: IWSMIP
  27. Kurianov P, Lipin A, Antropov A. et al. Popliteal Artery Angioplasty for Chronic Total Occlusions with versus without the Distal Landing Zone. Annals of Vascular Surgery. 2020:62. EDN: FCOWBP doi: 10.1016/j. avsg.2020.04.054
  28. Kram HB, Gupta SK, Veith FJ, et al. Late results of two hundred seventeen femoropopliteal bypasses to isolated popliteal artery segments. J Vasc Surg. 1991;14(3):386–390.
  29. Laxdal E, Jenssen GL, Pedersen G, et al. Subintimal angioplasty as a treatment of femoropopliteal artery occlusions. Eur J Vasc Endovasc Surg. 2003;25(6):578–582. doi: 10.1053/ejvs.2002.1899
  30. Löfberg AM, Karacagil S, Ljungman C, et al. Percutaneous transluminal angioplasty of the femoropopliteal arteries in limbs with chronic critical lower limb ischemia. J Vasc Surg. 2001;34(1):114–121. doi: 10.1067/mva.2001.113486
  31. Lees T, Troëng T, Thomson IA, et al. International Variations in Infrainguinal Bypass Surgery — a VASCUNET Report. Eur J Vasc Endovasc Surg. 2012;44(2):185–192. doi: 10.1016/j.ejvs.2012.05.006
  32. Loh A, Chester JF, Taylor RS. PTFE bypass grafting to isolated popliteal segments in critical limb ischaemia. Eur J Vasc Surg. 1993;7(1):26–30. doi: 10.1016/s0950-821x(05)80539-0
  33. Moxey PW, Hofman D, Hinchliffe RJ, et al. Trends and outcomes after surgical lower limb revascularization in England. Br J Surg. 2011;98(10):1373–1382. doi: 10.1002/bjs.7547
  34. Myint M, Schouten O, Bourke V, et al. A real-world experience with the Supera interwoven nitinol stent in femoropopliteal arteries: midterm patency results and failure analysis. J Endovasc Ther. 2016;23(3):433–441. doi: 10.1177/1526602816639543
  35. Mannick JA, Jackson BT, Coffman JD, et al. Success of bypass vein grafts in patients with isolated popliteal artery segments. Surgery. 1967;61(1):17–25.
  36. Narula N, Dannenberg AJ, Olin JW, et al. Pathology of peripheral artery disease in patients with critical limb ischemia. J Am Coll Cardiol. 2018;72(18):2152–2163. doi: 10.1016/j.jacc.2018.08.002
  37. Palena LM, Diaz-Sandoval LJ, Sultato E, et al. Feasibility and 1-year outcomes of subintimal revascularization with Supera® stenting of long femoropopliteal occlusions in critical limb ischemia: the “Supersub” study. Catheter Cardiovasc Interv. 2017;89(5):910–920. doi: 10.1002/ccd.26863
  38. Park UJ, Kim HT, Roh YN. Impact of tibial runoff on outcomes of endovascular treatment for femoropopliteal atherosclerotic lesions. Vasc Endovasc Surg. 2018;52(7):498–504. doi: 10.1177/1538574418779466
  39. Rueda CA, Nehler MR, Perry DJ, et al. Patterns of artery disease in 450 patients undergoing revascularization for critical limb ischemia: implications for clinical trial design. J Vasc Surg. 2008;47(5):995–999. doi: 10.1016/j.jvs.2007.11.055
  40. Romiti M, Albers M, Brochado-Neto FC, et al. Meta-analysis of infrapopliteal angioplasty for chronic critical limb ischemia. J Vasc Surg. 2008;47(5):975–981. doi: 10.1016/j.jvs.2008.01.005
  41. Acín F, Varela C, López de Maturana I, et al. Results of infrapopliteal endovascular procedures performed in diabetic patients with critical limb ischemia and tissue loss from the perspective of an angiosome-oriented revascularization strategy. Int J Vasc Med. 2014;2014:270539. doi: 10.1155/2014/270539
  42. Satiani B, Das BM. Predictors of success in bypass grafts to the isolated popliteal segment. Surg Gynecol Obstet. 1986;162(6):525–530.
  43. Siracuse JJ, Menard MT, Eslami MH, et al. Vascular Quality Initiative. Comparison of open and endovascular treatment of patients with critical limb ischemia in the Vascular Quality Initiative. J Vasc Surg. 2016;63(4):958–965. doi: 10.1016/j.jvs.2015.09.063
  44. Toursarkissian B, D’Ayala M, Stefanidis D, et al. Angiographic scoring of vascular occlusive disease in the diabetic foot: relevance to bypass graft patency and limb salvage. J Vasc Surg. 2002;35(3): 494–500. doi: 10.1067/mva.2002.120046
  45. Walden R, Adar R, Rubinstein ZJ, et al. Distribution and symmetry of arteriosclerotic lesions of the lower extremities: an arteriographic study of 200 limbs. Cardiovasc Intervent Radiol. 1985;8(4):180–182. doi: 10.1007/BF02552893
  46. Zhou M, Huang D, Liu C, et al. Comparison of hybrid procedure and open surgical revascularization for multilevel infrainguinal arterial occlusive disease. Clin Interv Aging. 2014;9:1595–603. doi: 10.2147/CIA.S66860

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. Example of a simultaneous distal hybrid intervention performed on a 64-year-old patient with CLTI and deep trophic changes in the lateral plantar artery: a — the introducer 6F is introduced antegradely via the lateral branch of the functioning femoral-popliteal shunt/bypass (FPB); b — selective direct angiography of the arteries of the popliteal-tibial segment, performed through the introducer: occlusion of all three tibial arteries; c — recanalization stage of the posterior tibial artery: the injection of contrast material into the lateral plantar artery through the lumen of the balloon catheter; d — the final result of the endovascular intervention: all three tibial arteries are functioning; e — direct angiosomal foot revascularization

Download (198KB)
