Intestinal malrotation in newborns and infants: comparative possibilities of ultrasound and radiologic methods of investigation

Cover Page

Cite item

Abstract

BACKGROUND: Intestinal malrotation is a congenital pathology that results from abnormal fixation and rotation of the midgut during fetal development. This pathological condition is most often diagnosed during the first month of life and is often manifested by the presence of regurgitation, restlessness, vomiting with an admixture of bile, low weight gain. The narrow root of the mesentery facilitates the formation of midgut ingestion, which can lead to ischemia and necrosis and requires urgent surgical intervention. Ultrasound and radiologic examination with contrast are currently used to diagnose malrotation.

AIM: To improve the diagnosis of intestinal malrotation in newborns and infants by carrying out a comparative analysis of the capabilities of radiologic and ultrasound methods of investigation when they are used in combination.

MATERIALS AND METHODS: Data from 112 patients aged from 1 day from birth to 3 months 26 days between 2016 and 2024 with ultrasound signs of malrotation detected by microconvex and linear transducers were analyzed. 50 children were further followed up with this provisional or final diagnosis. Contrast agent passages and irrigographs were performed on an AXIOM Luminos DRF (Siemens), with 1 to 15 radiographs and up to 8 X-ray examination series obtained.

RESULTS: The most common ultrasound sign of malrotation was atypical location of mesenteric vessels, and the most common radiologic sign was left-sided location of the colon and high standing of the cecum. Assessment of the location of the duodenojejunal junction was complicated in most cases. Surgery was performed in 17 children, one of them for suspected intestinal obstruction, and a ring-shaped pancreas was found in 4 patients. The diagnosis of malrotation was made in 40 children out of 50, in 4 cases this was discordant with the radiologic findings. Concomitant abnormal location of internal organs was detected in 12 patients.

CONCLUSION: Screening ultrasound examination of all newborns should be considered as the pathology may be asymptomatic. It is important to include suspicion of malrotation in the diagnosis because of the possible manifestation of the pathology at a later age. It is currently not possible to completely abandon radiologic examination with contrast in the diagnosis of malrotation.

About the authors

Kristina S. Anpilogova

Almazov Research Center of the Ministry of Health of the Russian Federation

Author for correspondence.
Email: kristina-anp@mail.ru
ORCID iD: 0000-0002-1128-1587

postgraduate student

Russian Federation, Saint Petersburg

Yana A. Filin

Almazov Research Center of the Ministry of Health of the Russian Federation

Email: filin_yana@mail.ru
ORCID iD: 0009-0009-0778-6396
Russian Federation, Saint Petersburg

Elena V. Polyakova

Almazov Research Center of the Ministry of Health of the Russian Federation

Email: polenav@mail.ru
ORCID iD: 0009-0009-2359-6330

MD, Ultrasound Diagnostic Physician

Russian Federation, Saint Petersburg

Anna A. Sukhotskaya

Almazov Research Center of the Ministry of Health of the Russian Federation

Email: sukhotskaya_aa@almazovcentre.ru
ORCID iD: 0000-0002-8734-2227

MD, Cand. Sci. (Medicine), the Head of Pediatric Surgery Department

Russian Federation, Saint Petersburg

Konstantin I. Sebelev

Almazov Research Center of the Ministry of Health of the Russian Federation

Email: ki_sebelev@list.ru
ORCID iD: 0000-0003-0075-7807

MD, Dr. Sci. (Medicine), Professor of Radiation Diagnostics and Medical Imaging with Clinic at the Institute of Medical Education Department

Russian Federation, Saint Petersburg

Gennady E. Trufanov

Almazov Research Center of the Ministry of Health of the Russian Federation

Email: trufanovge@mail.ru
ORCID iD: 0000-0002-1611-5000

MD, Dr. Sci. (Medicine), Professor

Russian Federation, Saint Petersburg

References

  1. Morozov DA, Pimenova ES. Tatochenko VK, et al. Surgical treatment of a rare combination of intestinal malrotation with secondary lymphangiectasia. Annals of the Russian Academy of Medical Sciences. 2015;70(1): 56–62. (In Russ.) EDN: TKUYUB doi: 10.15690/vramn.v70i1.1232
  2. Bass LM, Wershil BK. Anatomy, histology, embryology, and developmental anomalies of the small and large intestine. In: Feldman M, Friedman LS, Brandt LJ, eds. Sleisenger and Fordtran’s gastrointestinal and liver disease: Pathophysiology, Diagnosis, Management. Philadelphia, PA: Elsevier; 2015. P. 1649–1678.
  3. Toshmatov H.Z., Toshboev Sh.O. Abnormal embryogenesis as a pathogenetic factor of the development of intestinal malrotation. Universum: chemistry and biology. 2021;(3–1(81)):25–27. (In Russ.) EDN: LXDOUT
  4. Kim J, Yoo SY, Jeon TY et al. [Malrotation and Midgut Volvulus in Children: Diagnostic Approach, Imaging Findings, and Pitfalls]. Journal of the Korean Society of Radiology. 2024;85(1):124–137. [Article in Korean] doi: 10.3348/jksr.2023.0002
  5. Fokin AV, Alekseeva LN, Vaganov AA, et al. Magnetic resonant tomography of the whole body in children. Pediatric Bulletin of the Southern Urals. 2018;(2):72–80. (In Russ.) EDN: POIAIT
  6. Zhou LY, Li SR, Wang W, et al. Usefulness of sonography in evaluating children suspected of malrotation: comparison with an upper gastrointestinal contrast study. Journal of Ultrasound in Medicine. 2015;34(10):1825–1832. doi: 10.7863/ultra.14.10017
  7. Binu V, Nicholson C, Cundy T, et al. Ultrasound imaging as the first line of investigation to diagnose intestinal malrotation in children: safety and efficacy. Journal of Pediatric Surgery. 2021;56(12): 2224–2228. doi: 10.1016/j.jpedsurg.2021.04.009
  8. Yousefzadeh DK, Kang L, Tessicini L. Assessment of retromesenteric position of the third portion of the duodenum: an US feasibility study in 33 newborns. Pediatric radiology. 2010;40(9):1476–1484. doi: 10.1007/s00247-010-1709-4
  9. Toshmatov KhZ, Ergashev BB, Ajimamatov KhT, Toshboev ShO. Modern methods of diagnostics of intestinal malrotation in pediatric surgery. A new day in medicine. 2020;(1(29)):413–416. (In Russ.) EDN: AATEIY
  10. Strouse PJ. Ultrasound for malrotation and volvulus: has the time come? Pediatric radiology. 2021;51(4):503–505. doi: 10.1007/s00247-020-04919-3

Supplementary files

Supplementary Files
Action
1. JATS XML
2. Fig. 1. Left-sided location of the colon (left), high location of the cecum (right) in neonates, irrigography

Download (215KB)
3. Fig. 2. High and medial position of the cecum in a newborn, irrigography

Download (108KB)
4. Fig. 3. Duodenojejunal junction probably located to the right of the left vertebral body pedicle, fluoroscopy

Download (82KB)
5. Fig. 5. Whirlpool sign, or whirlpool symptom, detected in a newborn, color Doppler imaging

Download (248KB)
6. Fig. 6. Atypical location of mesenteric vessels: the artery (vessel with a thick, hyperechogenic wall) is located dorsally, to the right; the vein (vessel with a thin wall) — ventrally and to the left

Download (113KB)
7. Fig. 7. Example of duodenal dilatation in a newborn on ultrasound, B-mode (left). Second segment of the duodenum in a healthy newborn (right)

Download (159KB)
8. Fig. 4. Normal location of mesenteric vessels in a newborn, B-mode

Download (115KB)
