THE FORMATION OF CYCLIC SURFACES WITH VARIABLE RADIUS OF GENERATRIX CIRCLES IN AUTOCAD

Resumo

The possibility of the formation of the normal cyclic surfaces and cyclic surfaces in planes of the pencil in AutoCad is discussed in the article. It is shown that the formation of surfaces should be performed on the basis of their compartments. The algorithm of formation of cyclic surfaces, the fragments of programs for the performance of the proposed algorithm are given
