Fracture-Resistant Zirconia-Based Composite Ceramics with Increased Surface Layer Hardness

A. A. Dmitrievskiy; Дмитриевский А. А.; D. G. Zhigacheva; Жигачева Д. Г.; N. Yu. Efremova; Ефремова Н. Ю.; V. M. Vasyukov; Васюков В. М.; G. V. Grigoriev; Григорьев Г. В.

doi:10.31857/S1028096023080071

Fracture-Resistant Zirconia-Based Composite Ceramics with Increased Surface Layer Hardness

Authors: Dmitrievskiy A.A.¹, Zhigacheva D.G.¹, Efremova N.Y.¹, Vasyukov V.M.¹, Grigoriev G.V.¹
Affiliations:
1. Derzhavin Tambov State University
Issue: No 8 (2023)
Pages: 107-112
Section: Articles
URL: https://ogarev-online.ru/1028-0960/article/view/137804
DOI: https://doi.org/10.31857/S1028096023080071
EDN: https://elibrary.ru/OAKWKU
ID: 137804

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

A two-layer alumina toughened zirconia composite ceramic stabilized with calcium oxide (Ca-ATZ) was produced using a relatively economical powder metallurgy method. One of the layers contains silica additive (Ca-ATZ + SiO₂). The structure, elemental and phase composition as well as the complex of mechanical properties nearby of the Ca-ATZ/Ca-ATZ + SiO₂ interface has been investigated. It was shown that the presence of a sharp interface of layers with different elemental composition did not cause structural disorders (appearance of pores, cracks and other macroscopic defects that contribute to the deterioration of strength properties) or changes in the phase composition (more than 90% of zirconia in both layers was in the tetragonal phase, which provided a high role of the transformation toughening mechanism). Demonstrated preservation of structural integrity and ratio of monoclinic, tetragonal and cubic zirconia phases at formation of sharp interface of the mentioned layers, provides possibility of manufacturing of zirconia-based ceramics with thin (100–200 μm) modified layer. Taking into account the difference in mechanical properties of Ca-ATZ and Ca-ATZ + SiO₂ ceramics, this provides the basic material (containing SiO₂) increased fracture toughness (not less than 12 MPa m^1/2), and near surface layer (not containing SiO₂) high hardness (not less than 14 GPa).

Keywords

two-layer composite ceramics, microstructure, phase composition, surface modification, hardness, fracture toughness, composition interface.

References

Surface Modification of Biomaterials. Methods Analysis and Applications / Ed. Williams R. Woodhead Publishing, 2011.
Surface Modification by Solid State Processing / Ed. Miranda R. Woodhead Publishing, 2014.
Jain I.P., Agarwal G. // Surf. Sci. Rep. 2011. V. 66. P. 77. https://doi.org/10.1016/j.surfrep.2010.11.001
Egerton R.F // Micron. 2019. V. 119. P. 72. https://doi.org/10.1016/j.micron.2019.01.005
Ushakov I.V. // Proc. SPIE. Nanodesign Technol. Computer Simulations. 2007. V. 6597. P. 659714. https://doi.org/10.1117/12.726773
Ushakov I.V., Feodorov V.A., Permyakova I.J. // Proc. SPIE. Int. Soc. Optical Engineer. 2004. V. 5400. P. 265. https://doi.org/10.1117/12.555529
Tao F., Liu Y., Ren X., Wang J., Zhou Y., Miao Y., Ren F., Wei Sh., Ma J. // J. Energy Chem. 2022. V. 66. P. 397. https://doi.org/10.1016/j.jechem.2021.08.022
Alagatu A., Dhapade D., Gajbhiye M., Panjrekar R., Raut A. // Mater. Today: Proc. 2022. V. 60. P. 2245. https://doi.org/10.1016/j.matpr.2022.03.338
Koizumi M. // Ceram. Eng. Sci. Proc. 1992. V. 13. P. 333. https://doi.org/10.1002/9780470313954.ch33
Miyamoto Y., Kaisser W., Rabin B.H., Kawasaki A., Ford R.G. Functionally Graded Materials: Design, Processing, and Applications. New York: Springer Science & Business Media, 1999.
Pasha A., Rajaprakash B.M. // Mater. Today: Proc. 2022. V. 52. P. 379. https://doi.org/10.1016/j.matpr.2021.09.066
Sun J., Ye D., Zou J., Chen X., Wang Y., Yuan J., Liang H., Qu H., Binner J., Bai J. // J. Mater. Sci. Technol. 2023. V. 138. P. 1. https://doi.org/10.1016/j.jmst.2022.06.039
Sam M., Jojith R., Radhika N. // J. Manuf. Process. 2021. V. 68. P. 1339. https://doi.org/10.1016/j.jmapro.2021.06.062
Besisa D.H.A., Ewais E.M.M. // Mater. Res. Express. 2019. V. 6. P. 075516. https://doi.org/10.1088/2053-1591/ab177e
Ewais E.M.M., Besisa D.H.A., Zaki Z.I., Kandil A.E.H.T. // J. Eur. Ceram. Soc. 2012. V. 32. P. 1561. https://doi.org/10.1016/j.jeurceramsoc.2012.01.016
Dmitrievskii A.A., Zhigachev A.O., Zhigacheva D.G., Rodaev V.V. // Tech. Phys. 2020. V. 65. № 12. P. 2016. https://doi.org/10.1134/S1063784220120075
Dmitrievskiy A.A., Zhigacheva D.G., Vasyukov V.M., Ovchinnikov P.N. // J. Phys. Conf. Ser. 2021. V. 2103. P. 012075. https://doi.org/10.1088/1742-6596/2103/1/012075
Dmitrievskiy A.A., Zhigacheva D.G., Grigoriev G.V., Ovchinnikov P.N. // J. Surf. Invest. X-Ray. Synchrotron and Neutron Techn. 2021. V. 15. V. 1. P. S137. https://doi.org/10.1134/S1027451022020264
Anstis G.R., Chantikul P., Lawn B.R., Marshall D.B. // J. Am. Ceram. Soc. 1981. V. 64. № 9. P. 533. https://doi.org/10.1111/j.1151-2916.1981.tb10320.x
Zhang F., Lin L.F., Wang E.Z. // Ceram. Int. 2015. V. 41. P. 2417. https://doi.org/10.1016/j.ceramint.2015.06.081
Garvie R.C., Hannink R.H.J., Pascoe R.T. // Nature. 1975. V. 258. P. 703. https://doi.org/10.1038/258703a0
Hannink R.H.J., Kelly P.M., Muddle B.C. // J. Am. Ceram. Soc. 2000. V. 83. № 3. P. 461.https://doi.org/10.1111/j.1151-2916.2000.tb01221.x
